4105A KYORITSU
Description
4105A KYORITSU
Measurement
Ranges
Earth Resistance: 0~20Ω/0~200Ω/0~2000Ω
Earth Voltage [50,60Hz]: 0~200V AC
Accuracy
Earth Resistance: ±2%rdg±0.1Ω (20Ωrange)
|±2%rdg±3dgt (200Ω/2000Ωrange)
Earth Voltage: ±1%rdg±4dgt
Overload Protection
Earth Resistance: 280V AC for 10 seconds
across 2 of the 3 terminals
Earth Voltage: 300V AC for 1 minute
Safety Standard
IEC 61010-1 CAT.III 300V Pollution Degree 2, IEC 61557
Applicable Standards
IEC 60529 IP54
Withstand Voltage
3700V AC for 1 minute
Power Source
R6P (AA) (1.5V) × 6
Dimensions
105(L) × 158(W) × 70(D)mm
Weight
550g approx.
Accessories
7095A (Earth resistance test leads) × 1set
(red-20m, yellow-10m, green-5m)
8032 (Auxiliary earth spikes) × 1set
7127A (Simplified measurement probe) × 1set
R6P (AA) × 6
Neck strap
Instruction Manual
Carrying Case
: 4105A (Soft case)
: 4105A-H (Hard case)
Optional
7100 (Precision measurement cord set)
