Product Description
45mm DIN Achromatic Objective: 4X, 10X, 40(S), 100X(S, Oil)
Wide Field Plane-Scope Eyepiece: : WF10X;
Total Magnification: 40X-1000X
Articulated Free Binocular Head,
Interpupillary Distance: 55-75mm,
30° Inclined, 360° Rotatable
Double Layers Mechanical Stage: 125X125mm,
Moving Range X-Y: 60X40mm
ø 2-ø 30mm Iris Diaphragm And ø 32 Filter;
ABBE Condenser: N. A. 1.25
Coaxial Coarse And Fine Focusing Adjustable Mechanism: 14mm
Built-in Adjustable Brightness LED Lamp
