The HCO0-2 Heating HPLC Column Oven offers the reliability of a completely solid-state system. The only moving parts in the unit are the chamber fan and the cooling fan, while its Peltier-based design removes the need for compressors or CFCs. The energy efficient HCO0-2 uses a maximum of 230 watts of power—less than many light bulbs.
The chamber of the HCO0-2 is epoxy-painted aluminum and resistant to most solvents. The mounting posts for the columns are mounted on the door, offering easy access to the columns, valve and fittings when the door is open.
Product Manuals
HCO0-2
Features
Peltier driven for heating and chilling. No CFC’s
Temperature range from Room tem.to 70.0 C.
Accurate to +/- 0.2 C . Stability to +/- 0.2 C
Chamber uniformity +/- 0.5 C
Chamber door opens down from top for easy, unobstructed mounting of columns
Mounting hole provided for valve in the door
Capacity 4-30 cm by 1″ columns with fittings
Separate drains for valve and spills
Electronic calibration held
Timer to 99 hours with audible alarm and user settable Auto-Off
Operates at 230VAC and are intrinsically safe. Built to ETL, CSA and CE standards
Provided with universal power supply for use anywhere in the world
12-month warranty
Applications
Constant temperature control HPLC at room temperature for more accurate results
Exact temperature control of normal phase HPLC with RID for optimal answers
Impurity chromatography
Chiral chromatography
Chilling and heating of columns for methods development
