Overview & Functionality
-
Application: Designed to evaluate human muscle fatigue by analyzing muscle contraction frequency, duration, speed, and pull/relaxation curves.
-
Mechanism: Features a pistol-style handle with a trigger mechanism connected to an adjustable spring tensioning system.
-
Recording System: Uses a nylon line connected through a pulley system to an ink-writing stylus, fed by a built-in reservoir to plot movements.
-
Compatibility: Easily adaptable for connection with a transducer.
Key Specifications
-
Base Dimensions: Aluminum base measuring 125 mm (5 inches) in width by 500 mm (20 inches) in length, providing full forearm support.
-
Adjustability: Features adjustable height settings, adjustable spring tensioning, and two width-adjustable upright supports for securing and studying the wrist.
