Features and benefits
- 200 A AC and DC current measurement with detachable jaw
- 600 VAC and DC voltage measurement
- Detachable jaw makes accessing wires and viewing the display easier
- Built in flashlight/torch allows for easy illumination and identification of wires
- CAT III 600 V
- Compact design fits in your hand and can be used while wearing protective equipment
- State of the art signal processing allows for use in noisy electrical environments while providing stable readings
- Large, easy to read, backlight display automatically sets the correct measurement range so you do not need to change switch positions while taking a measurement
| Specifications | |
| Diameter of measurable conductor | 0.71 in or 18 mm max |
| Operating temperature | -14 to 122ºF (-10 to 50ºC) |
| Storage temperature | -40 to 140ºF (-40 to 60ºC) |
| Operating humidity | < 90% at 10 to 30ºC, < 75% at 30 to 40ºC |
| Operating altitude | 0 to 2000 m |
| Size | 225 x 65 x 46 mm, (8.858 x 2.559 x 1.811 in.) |
| Weight | 275 g, (10 oz.) |
| Temperature coefficient | 0.01% ºC (< 18ºC or > 28ºC) |
