Microlab BC-300 – Auto Hematology Analyzer
The Microlab BC-300 is a compact, fully automated 3-part differential hematology analyzer designed for complete blood count (CBC) testing in clinical laboratories, hospitals, and diagnostic centers. The analyzer delivers accurate and reliable hematology results with low sample and reagent consumption, making it ideal for routine laboratory applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Microlab BC-300 |
| Type | Automated 3-Part Differential Hematology Analyzer |
| Differential | 3-Part WBC Differential |
| Parameters | 19 Parameters + 3 Histograms |
| Throughput | Up to 60 Samples/Hour |
| Measurement Principle | Electrical Impedance Method and Cyanide-Free Hemoglobin Method |
| Sample Modes | Whole Blood and Prediluted |
| Sample Volume | 13 µL (Whole Blood), 20 µL (Prediluted) |
| Display | Large Color LCD Display |
| Data Storage | Up to 35,000 Sample Results with Histograms |
| Histograms | WBC, RBC, and PLT Histograms |
| Printer | Built-in Thermal Printer |
| Interfaces | RS-232 Ports, Keyboard Interface, Optional Barcode Scanner |
| Operating Temperature | 15°C to 30°C |
| Relative Humidity | 30% – 85% RH |
| Power Supply | AC 100–240 V, 50/60 Hz |
| Dimensions (W × D × H) | 390 × 400 × 460 mm |
| Weight | Approximately 21 kg |
