Features:
1. Electronic stepless speed controll.
2. LED display.
3. Optional explosion-proof function.
Technical Parameters:
| Model | RE-201D | RE-301 | RE-501 | RE-1002 | RE-2002 | RE-5003 |
| Rotary Bottle | 1L 24# Standard mouth | 3L flange φ50 | 5L flange φ50 | 10L flange φ95 | 20L flange φ95 | 50L flange φ125 |
| Collecting Bottle | 1L 35#(Standard mouth) | 2L 35#(Ball mill mouth) | 3L 35#(Ball mill mouth) | 5L(Flange φ60~50) | 10L(Flange φ60) | 20L(Flange φ60~50) |
| Condenser | Vertical φ85*430mm,
35#(Ball mill mouth) |
Vertical
φ100*530mm |
Vertical
φ100*530mm |
Vertical three backflow
φ120*620mm(main), φ135*475mm(SUB) |
Vertical three backflow φ130*700mm(main), φ160*530mm(SUB) | Vertical three Backflow
φ160*835mm(main), φ160*530mm(SUB) |
| Charging Valve | 19#(Standard size） | 34#(Standard size） | 40#(Standard size） | |||
| Rotary Speed | 0~120rpm | |||||
| Vacuum | 0.098Mpa | 0.095Mpa | ||||
| Temp. Range | RT~180℃ | |||||
| Temp. Accuracy | ±1℃ | |||||
| Stroke Height | 200mm | 180mm | ||||
| Rotary Power | 40W | 40W | 120W | 180W | ||
| Heating Power | 1KW | 2KW | 3KW | 5KW | 8KW | |
| Shelf Material | Stainless steel | Coating anticorrosive | ||||
| Chamber Material | SS 245*140mm | SS 265*160mm | SS 280*170mm | SS 350*220mm | SS 450*260mm | SS 550*320mm |
| Plate size | 280*330mm | 350*330mm | 534*504mm | 474*474mm | 550*320mm | |
| Power Supply | Standard: AC220V, 50/60Hz; Optional: AC110V, 60Hz | AC220V, 50/60Hz | Standard: AC380V, 50Hz; Optional: AC220V, 50Hz | |||
| External Size(mm) | 700*330*785 | 740*330*970 | 760*330*1030 | 930*560*1910 | 1000*600*2130 | 1330*730*2340 |
| Package Size(mm) | 710*540*350 | 990*640*470 | 1320*780*755 | 1350*670*720
680*680*790 |
1420*820*720
830*730*910 |
|
| Gross Weight | 21kg | 40kg | 42kg | 107kg | 136kg | 186kg |
| Standard
Accessory |
1L rotary bottle*1,
1L collecting bottle*1 |
3L rotary
bottle*1, 2L collecting bottle*1 |
5L rotary bottle*1,
3L collecting bottle*1 |
10L rotary bottle*1,
5L collecting bottle*1 |
20L rotary bottle*1,
10L collecting bottle*1 |
50L rotary bottle*1,
20L collecting bottle*1 |
| Optional Accessory | Vacuum pump, Recirculating chiller | |||||
