Water Bath – Model HH-S6 (6-Hole Digital Thermostatic Water Bath)
The HH-S6 Digital Thermostatic Water Bath is a microprocessor-controlled laboratory water bath designed for precise temperature-controlled heating of samples. It is widely used for incubation, distillation, drying, concentration, and heating of chemical and biological samples in laboratories and research facilities.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | HH-S6 |
| Type | Digital Thermostatic Water Bath |
| Number of Holes | 6 Holes (Double-Row Design) |
| Temperature Range | Ambient +5°C to 99.9°C |
| Temperature Accuracy | ±0.5°C |
| Temperature Fluctuation | ≤ ±1°C |
| Heating Power | 1500 W |
| Tank Capacity | Approximately 22.5–24 Liters |
| Inner Tank Material | Stainless Steel (SUS304) |
| Inner Tank Dimensions | 500 × 300 × 160 mm |
| External Dimensions | 610 × 330 × 210 mm |
| Display | LED Digital Temperature Display |
| Power Supply | AC 220 V, 50 Hz |
| Operating Environment | 5°C to 40°C, Relative Humidity ≤80% |
